Welcome to Retro Commodore – Your place with high quality scans.

If you like the contents here, please like us on Facebook.

Feel free to browse the collection using the menu. Hover, don’t click, using the mouse to expand the menu.

If you have something missing from the site and want to donate/lend us, please use the contact form on the About page.

As this is an international site we’d prefer that comments are kept in English.

Joystick Breakout and cleanup on Electronics projects

Added is the Joystick Breakout, which is a small board where you can do measurements on signals to/from the joystick ports. It’s meant for development and/or diagnostics, if you find more uses for it, please let me know 🙂



Both a male and female DB9 connector for wires is needed.

I’ve also done a lot of cleanup on Github, normalizing directory names, streamlined the products etc. This should make it easier to identify if you have many projects in the same folder.

There are quite a few products on their way, once I’ve tested them that is.

Checkmate A1500 plus

With permission and thanks to Steve Jones, the newly created Checkmate A1500 plus enclosure manual, is now added.

If you missed out on the kickstarter, on this awesome enclosure, you can sign up to get one from the next batch.

Head over to https://www.checkmate1500plus.com/ and check out what options you have.
